High Efficiency: The PH5000 TM Series boasts a high conversion efficiency, ensuring that a significant portion of the solar energy captured is converted into electricity.
This efficiency helps maximize the return on investment for solar system owners.
Wide MPPT Voltage Range: This inverter features a wide Maximum Power Point Tracking (MPPT) voltage range, allowing it to adapt to various solar panel configurations and weather conditions. This feature ensures optimal energy harvesting.
On-Grid Operation: The PH5000 TM Series is designed for on-grid applications, meaning it synchronizes with the utility grid. It feeds excess energy back into the grid, potentially earning users credits through net metering.
High-Frequency Switching: Utilizing high-frequency switching technology, this inverter achieves faster response times and lower energy losses. It ensures that the system operates efficiently even during rapid changes in solar irradiance.
LCD Display: An intuitive LCD display provides real-time information about the system's performance, including input and output voltages, current, and energy production. Users can easily monitor their solar system's operation.
Advanced Protection: Guanye® has incorporated a comprehensive set of protection features into this inverter, including overvoltage protection, overcurrent protection, and anti-islanding protection. These safeguards protect both the inverter and the connected solar array.
Technical Specifications:
Power Output: The PH5000 TM Series is available in two power ratings, 12kW and 15kW, catering to a wide range of solar system sizes.
Input Voltage Range: It accepts a wide range of DC input voltages, typically around 200-800VDC, accommodating various solar panel configurations.
Maximum Efficiency: The inverter achieves a peak efficiency of over 98%, ensuring minimal energy losses during the conversion process.
MPPT Voltage Range: The MPPT voltage range is typically between 300-800VDC, allowing for flexible solar array configurations.
Grid Connection: The inverter is designed for on-grid operation and connects seamlessly with the utility grid.
Display: The LCD display provides valuable information, including input and output voltages, current, power output, and system status.
Dimensions: The inverter's physical dimensions are approximately [provide dimensions], making it relatively compact and easy to install.
Benefits:
Energy Savings: The high efficiency of the PH5000 TM Series ensures that solar energy is effectively converted into electricity, resulting in significant energy savings over time.
Grid Interaction: On-grid operation allows users to take advantage of net metering, reducing electricity bills and potentially earning credits for excess energy production.
Reliability: Guanye® is known for producing reliable and durable inverters, ensuring long-term performance and peace of mind for system owners.
User-Friendly: The LCD display and user-friendly interface make it easy for users to monitor and control their solar system.
Safety: The inverter's advanced protection features safeguard both the inverter and the solar array, enhancing system safety.
Compatibility: Its wide MPPT voltage range and power output options make it compatible with a variety of solar panel configurations and system sizes.
